Victron SmartSolar MPPT 100/20 Solar Charge Controller (Bluetooth)
£79.00
Skip to product information
Victron SmartSolar MPPT 100/20 Solar Charge Controller (Bluetooth)
£79.00
More headroom for bigger panels or two in series. The SmartSolar MPPT 100/20 handles up to 100V of panel voltage and 290W at 12V, with Bluetooth built in.
Key features
- 20A charging, up to 290W at 12V (580W at 24V, 1160W at 48V)
- 100V PV input for series panel wiring
- Ultra-fast MPPT, up to 98% efficient
- Built-in Bluetooth for the VictronConnect app
- 20A load output with battery-protect function
- VE.Direct port; 5-year Victron warranty
Specifications
| Part number | SCC110020160R |
| System voltage | 12/24/48V auto |
| Max. charge current | 20A |
| Max. PV power | 290W (12V) / 580W (24V) / 1160W (48V) |
| Max. PV open-circuit voltage | 100V |
| Max. PV short-circuit current | 20A (18A at 48V) |
| Peak efficiency | 98% |
| Load output | 20A |
| Self consumption | 25mA |
| Max. cable size | 6mm² |
| Operating temperature | -30 to +60°C |
| Dimensions | 100 × 113 × 60mm |
